TBS M10Q GPS GLONASS

Current sensor for the TBS CORE. This is the 25A version. It’s compatible with other OSDs as well although we can’t take responsibility for that.

Try Fpv Shopping Event

Hurry and get discount up to 5%

Sale_coupon_15

₹1,498.00

Compare
Add to wishlist
18 People watching this product now!
  • Pick up from the Try Fpv Store

To pick up today

Free

  • Courier delivery

Our courier will deliver to the specified address

2-3 Days

Free

  • DHL Courier delivery

DHL courier will deliver to the specified address

2-3 Days

Free

  • Warranty 1 year

More details

  • Free 30-Day returns

More details

Payment Methods:

Description

Specification

  • Chipset – ublox UBX-M10050
  • Flash memory for saving configuration.
  • Frequency – L1, 1575.42MHz ; L2,1561.10MHZï¼›L3,1602.00MHZ
  • Baud Rate – 4800bps-921600bps, default 115200bps
  • Channel – N/a
  • Sensitivity – (Tracking: -166dBm) | (Capture: -160dBm) | (Cold Start – 148dBm)
  • Cold start – Average 26 seconds
  • Warm start – Average 24 seconds
  • Hot start – Average 1 second
  • Accuracy – (HorizontalPosition:Autonomous<2m average) | (SBAS < 2.0m average) | (Timepulse signal: RMS 30 ns)
  • Maximum height – 50000m
  • Maximum speed – 500 m/s
  • Maximum acceleration – ≦ 4G
  • Refresh Rate – 0.25Hz-18Hz, default 1Hz
  • Size – 25 x 25 x 7.7mm
  • Weight – 13.5g
  • Input Voltage – 5V
  • Magnetometer: QMC5883
